FRH44S Non-Return Flange End Swing Type Check Valve with plastic UPVC PVDF body

FREE-VALVE FRH44S Non-Return Flange End Swing Type Check Valve refers to the valve that automatically opens and closes the disc by relying on the force generated by the flow of the medium itself to prevent the medium from backflowing.

FRH44S Plastic PVDF UPVC Double Flange End Swing Non-Return Check Valve

Content

FREE-VALVE FRH44S Non-Return Flange End Swing Type Check Valve refers to the valve that automatically opens and closes the disc by relying on the force generated by the flow of the medium itself to prevent the medium from backflowing.Plastic swing check valves are swing type and have a plastic disc that swings about a hinge pin or shaft,the valves are normally designed for horizontal flow condition, the flow should be in upwards direction and under the disc.This series of check valves is widely used in pipeline transmission lines with corrosive media.

Features

The eccentric mounted hinge pin in combination with the disc seat guarantees a positive shut off of the returning medi
Bolt bonnetprovides easy access to the disc and hinge pin without removing the valve from the pipeline in case of maintenance.
Disc nut secures the disc to the hingeand allows the disc to rotate about pin axis and assist in tight shut off.
Working temperature:FRPP -14ºC~ +90ºC,UPVC -10ºC~ +60ºC,PVDF -40ºC~ +150ºC,CPVC -20ºC~ +95ºC
Fasteners can be made of engineering plasticsin contact with the medium, so that the valve is more corrosion resistant.
Low liquid flow resistance,the inner wall of plastic molding products is smooth, and the friction coefficient is small.
Excellent chemical properties: this product, tasteless, acid and alkali resistance, corrosion resistance, wide range of use.

Technical Specification:

Size Range: NPS2~NPS12,DN50~DN300
Applicable Temperature:-20~120℃
Connection Type: Flange
Flange ends:GB/T9113,ASME B16.25
Body material：RPP, PVDF, CPVC, UPVC
Test standard：GB/T13927,API598
Flange To Flange:ANSI B 16.10,GB/T12221

Application:

FREE-VALVE FRH44S Non-Return Flange End Swing Type Check Valve body is light weight, strong corrosion resistance, a wide range of applications, wear resistance, easy to disassemble, easy to maintain, the valve is widely used in water, air, oil, corrosive chemical liquids.This series of check valves is widely used in pipeline transmission lines with corrosive media.
