Fluorine Lined Ball Valve

We will make the testing of magnetic limited switch ，it will be installed at pneumatic ceramic lined double disc gate valve .

Ceramic valve disc is mainly used in pneumatic ceramic double gate valves, pneumatic ceramic swing gate valves,

Pneuamtic dome valve opening and closing test

FREE-VALVE’s  Split body WCB Body Aluminum oxide Y type slurry valve  is ideal for many applications because the valves are designed for use on abrasion materials.  Split body WCB Body Aluminum oxide Y type slurry valve is divided into left and right parts with a seat between them. The bolt connecting the two parts can be dissembled to replace the valve seat.The valve with abrasion resistance,high pressure resistance,erosion resistance and anti-scabbing performance.

Pneumatic metal seated rotating disc gate valve is designed for higher temperature in the fly ash system at coal power plant

Pneumatic ceramic lined double disc gate valve is designed for fly ash at ash handling system in coal fired power plant

FREE-VALVE’s Pneumatic Ceramic Rotary Gate Valves are designed for pressurized and vacuum systems including pneumatic conveying systems, discharge and vent applications in steel plant and coal power. The whole of ceramic sealing faces of the valves are well ground and polished, which is ensure a reliable sealing performance of the valve.

FREE-VALVE brand Stainless steel pneumatic ceramic lined knife gate valves are known as slurry gate valves.With simple structure and can cut off medium which contains solid particles and fibers, suitable for some very hard particles or serious erosive mediums.They are installed to replace general metal seated knife gate valves which will be washed out easily, especially suitable for any power plant located on sea side .

FREE-VALVE brand Pneumatic operated dome valves are designed for ash handling system.Dome valve is unique in its ability to open and close with a tight pressure seal in environment where abrasive material are passing.Dome valve can achieve operating reliability in severe applications .

FREE-VALVE’s Pneumatic Ceramic Double Disc Gate Valve is mainly used in feeding and dumping the dry powder and the transport pipeline, which not only adopt toughening ceramic as shut off and wear out resistance material,

Sealing Test For FREE-VALVE Brand Pneumatic Ceramic Lined Double Disc Gate Valve

FREE-VALVE’s pneumatic and manual operating flat tank flush bottom valves are designed for the convenient and fast discharging the material or samples from the bottom of the reactor,drain or feed vessel .The valve can be welded or installed on the vessel through the flange at the bottom of the valve or on tank wall.

Ceramic ball machining is a part of machining process of the ceramic lined ball valve .The ceramic ball has anti abrasive and anti corrosive performance .

FREE-VALVE brand Pneumatic Ceramic Lined Knife Gate Valves are known as slurry gate valves. Its have simple structure and can cut off medium which contains solid particles and fibers, but for some very hard particles or serious erosive mediums, general metal seated knife gate valves will be washed out easily, so ceramic knife gate valves are very suitable for those mediums containing fibers and hard solid particles.

Open and close test for pneumatic ceramic lined double disc gate valve

Adjustment for Pneuamtic Ceramic Lined V Type Control Ball Valve

FREE-VALVE’s FRZ644TC Flange end Pneumatic Actuator Ceramic Twin Disc Balance Gate Valve is mainly used in feeding and dumping the dry powder and the transport pipeline, which not only adopt toughening ceramic as shut off and wear out resistance material

Pneumatic hard alloy seated rotating disc gate valves are designed for higher temperature in the fly ash system at coal power plant ,less than 350 Degree

Pneumatic metal seated double disc gate valve is designed for higher temperature in the fly ash system at coal power plant ,opening test is made before the valve leave factory.

FREE-VALVE’s Pneumatic swing tungsten carbide single plate gate valve are suitable for steel plant, cereals transport system, cement transport systems,ECO system,GAH system and EP system in coal fired power plant. In these applications, pneumatic conveying method is used to reduce manpower demand, and improve system efficiency and reliability, and is easy to realize automation.

Pneumatic hard alloy double disc rotary gate valve is designed for higher temperature in the fly ash system at coal power plant

FREE-VALVE brand Ceramic Lined Knife Gate Valves are known as slurry gate valves. Its have simple structure and can cut off medium which contains solid particles and fibers, but for some very hard particles or serious erosive mediums, general metal seated knife gate valves will be washed out easily, so ceramic knife gate valves are very suitable for those mediums containing fibers and hard solid particles.

Pneumatic ceramic lined rotating disc gate valve will be installed at ash handling system in thermal power plant

FREE-VALVE’s Pneumatic Anti wear Ceramic Rotary Gate Valves are designed for pressurized and vacuum systems including pneumatic conveying systems, discharge and vent applications in steel plant and coal power.

FREE-VALVE brand manual fluorine lined diaphragm valves are widely used in chemical industry, medicine and other industrial sectors to achieve the cutting of acid, alkali and other corrosive media in the production process

Sealing pressure test for the ceramic lined V type ball valve ,test medium is Air

FREE-VALVE brand swing arc valves are designed for ash handling system.They use a spherical-shape dome and an inflatable-seal to ensure a 100% airtight seal.swing arc valve is unique in its ability to open and close with a tight pressure seal in environment where abrasive material are passing.Dome valve can achieve operating reliability in severe applications .

DN100 PN10 pneumatic ceramic lined double disc gate valve

These pneumatic ceramic back forth sliding gate valve are produced for one of Mexico Customer.

FREE-VALVE brand Pneumatic Ceramic Lined Three-Way Changeover Gate Valve is a commutator separating the materials conveyed in one way into two ways. The valve is designed with one inlet port and two outlet ports, of which one outlet port is set forward along the direction of the main pipe, and the other outlet port is set below the main pipe or horizontal direction, and there is an angle with the main pipe
